涤纶针织物碱减量和染色一浴一步法工艺

doi:10.13475/j.fzxb.20180907508

纺织学报 ›› 2020, Vol. 41 ›› Issue (01): 80-87.doi: 10.13475/j.fzxb.20180907508

涤纶针织物碱减量和染色一浴一步法工艺

王小艳¹, 杜金梅¹, 彭铃淇¹, 荆丽丽², 许长海¹()

1.生态纺织教育部重点实验室(江南大学), 江苏无锡 214122
2.蓬莱嘉信染料化工股份有限公司, 山东蓬莱 265600

收稿日期:2018-09-28 修回日期:2019-10-21 出版日期:2020-01-15 发布日期:2020-01-14
通讯作者: 许长海
作者简介:王小艳(1994—),女,硕士生。主要研究方向为生态染整技术。
基金资助:
江苏省“六大人才高峰”资助项目(XCL-012)

Alkali reduction and one-bath-one-step process for dyeing polyester knitted fabric

WANG Xiaoyan¹, DU Jinmei¹, PENG Lingqi¹, JING Lili², XU Changhai¹()

1. Key Laboratory of Eco-Textiles (Jiangnan University), Ministry of Education, Wuxi, Jiangsu 214122, China
2. Penglai Jiaxin Dye Chemical Co., Ltd., Penglai, Shandong 265600, China

Received:2018-09-28 Revised:2019-10-21 Online:2020-01-15 Published:2020-01-14
Contact: XU Changhai

摘要/Abstract

摘要：

为解决常规涤纶织物染整加工需要碱减量、染色、还原清洗、水洗分步分浴进行所带来的耗时耗能等问题,使用耐碱分散染料,采用“碱减量和染色一浴一步法”工艺对涤纶针织物进行染整加工。分别探讨一浴一步法工艺中烧碱质量浓度、温度、时间对涤纶针织物性能的影响,得到最优工艺:处理温度为130 ℃,保温时间为50 min,烧碱质量浓度为10 g/L。结果表明:使用相同的染料、助剂及烧碱量对涤纶针织物处理,采用一浴一步法工艺得到织物的染色深度值比常规工艺处理得到的织物大,增深10%左右,若要达到相同的颜色,一浴一步法工艺可有效节省染料的用量;采用一浴一步法得到的染色涤纶针织物能达到免还原清洗的效果,染色产品色光稳定,色牢度优异。

关键词: 涤纶针织物, 耐碱分散染料, 涤纶染色, 碱减量, 一浴一步法, 染色性能

Abstract:

Polyester knitted fabrics are conventionally dyed with a process consisting alkali reduction, high temperature and high pressure exhaust dyeing, reduction cleaning, and washing. These steps are taking place individually, consuming more time and energy. To solve this problem in this research, polyester knitted fabrics were dyed with alkali-resistant disperse dyes under an alkali condition called one-bath-one-step exhaust dyeing and alkali reduction process. Influences of the dosage of sodium hydroxide, process temperature and duration on the properties of polyester fabrics using the one-bath-one-step process were investigated. An optimized process was obtained as follows: sodium hydroxide 10 g/L, temperature of 130 ℃ and duration of 50 min. It was found that compared with the ones obtained by conventional dyeing process, polyester fabrics treated with the one-bath-one-step process exhibited dyeing depth values 10% higher than the conventional dyeing process. This means that in order to achieve the same color, the use of one-bath-one-step process could save effectively the dosage of dyes. The dyed polyester fabrics treated with the one-bath-one-step process were stable in color and demonstrated excellent colorfastness.

Key words: polyester knitted fabric, alkali-resistance disperse dye, dyeing of polyester, alkali reduction, one-bath-one-step process, dyeing behavior

中图分类号:

TS192.5

王小艳, 杜金梅, 彭铃淇, 荆丽丽, 许长海. 涤纶针织物碱减量和染色一浴一步法工艺[J]. 纺织学报, 2020, 41(01): 80-87.

WANG Xiaoyan, DU Jinmei, PENG Lingqi, JING Lili, XU Changhai. Alkali reduction and one-bath-one-step process for dyeing polyester knitted fabric[J]. Journal of Textile Research, 2020, 41(01): 80-87.

图/表 13

图1

图2

图3

表1

图4

图5

图6

表2

图7

表3

表4

表5

表6

参考文献 16

[1]	张有定. 我国涤纶市场现状与发展趋势[J]. 合成纤维, 2013,42(11):1-4.
	ZHANG Youding. China's polyester market situationan-d development trend[J]. Synthetic Fiber in China, 2013,42(11):1-4.
[2]	SHEKH Md Mamun Kabira, JOONSEOK Koh. Alkaline w-eight reduction and dyeing properties of black doped-yed poly(ethyleneterephthalate) microfibre fabrics[J]. Coloration Technology, 2017,133(3):209-217. doi: 10.1111/cote.2017.133.issue-3
[3]	戴杰, 郭晓玲, 申国栋, 等. 碱减量和等离子体处理对涤纶织物的影响[J]. 针织工业, 2015,42(5):52-54.
	DAI Jie, GUO Xiaoling, SHEN Guodong, et al. Effects of alkali deweighting and plasma finishing on polyester fabric[J]. Knitting Industries, 2015,42(5):52-54.
[4]	曹机良, 孟春丽, 曹毅, 等. 烷基咪唑类双子型离子液体对涤纶织物的碱减量处理[J]. 纺织学报, 2018,39(1):79-83.
	CAO Jilaing, MENG Chunli, CAO Yi, et al. Alkali deweighing of polyester fabrics using alkyl imidazolium Gemini ionic liquid.[J] Journal of Textile Research, 2018,39(1):79-83.
[5]	盛连波. 涤纶染色与分散匀染剂研究[D]. 苏州:苏州大学, 2017:7-10.
	SHENG Lianbo. Study on polyester dyeing and disper-sing leveling agents[D]. Suzhou:Soochow University, 2017:7-10.
[6]	叶思佳, 杜奕铃, 张永高, 等. 涤纶起绒织物着色烂花印花中分散染料的耐碱性[J]. 纺织学报, 2018,39(1):98-103.
	YE Sijia, DU Yiling, ZHANG Yonggao, et al. Alkali resistance of disperse dyes in colored burnt-out printing on polyester fleece fabric[J]. Journal of Textile Research, 2018,39(1):98-103.
[7]	赵涛. 染整工艺与原理[M]. 北京: 中国纺织出版社, 2009:164,182.
	ZHAO Tao. Principle of dyeing and finishing: I[M]. Beijing: China Textile & Apparel Press, 2009:164,182.
[8]	ZHAO Yanmin. Harms of oligomers during polyester yarn dyeing and the research and application of oligomerreduce agent[J]. Ningbo Chemical Industry, 2007(2):10-13.
[9]	纪惠军, 范雪荣. 新型剥色体系还原清洗分散染料染色涤纶织物的研究[J]. 印染助剂, 2007,23(2):34-36.
	JING Huijun, FAN Xuerong. Study on reductive cleaning of disperse dyed polyester fibers with new stripping systems[J]. Textile Auxiliaries, 2007,23(2):34-36.
[10]	黄茂福, 王益民. 取代保险粉的新还原剂[J]. 染整技术, 2006,28(3):28-30.
	HUANG Maofu, WANG Yiming. New reducing agent to replace sodium hydrosulphite[J]. Textile Dyeing and Finishing Journal, 2006,28(3):28-30.
[11]	曹机良, 孟春丽, 陈云博. 涤纶高温高压碱减量和染色一浴加工[J]. 染整技术, 2016,38(9):26-32,35.
	CAO Jiliang, MENG Chunli, CHEN Yunbo. One-bath dyeing and alkali peeling of polyester fabric under high temperature and pressure[J]. Textile Dyeing and Finishing Journal, 2016,38(9):26-32,35.
[12]	高丽贤. 涤纶织物分散染料减染一浴法染色[J]. 染整技术, 2014,36(6):25-27.
	GAO Lixian. Polyester fabric alkali peeling and dyeing with disperse dyes in one-bath process[J]. Textile Dyeing and Finishing Journal, 2014,36(6):25-27.
[13]	姚平. 涤纶织物的碱减量处理及其性能探讨[J]. 轻工科技, 2014,20(12):92-93.
	YAO Ping. Discussion on alkali reduction treatment and properties of polyester fabric[J]. Journal of Light Industry, 2014,20(12):92-93.
[14]	倪人捷, 黄煜. 阳离子Gemini 表面活性剂对涤纶织物的匀染性能研究[J]. 广东化工, 2012,38(18):6-7.
	NI Renjie, HUANG Yu. The research on levelling capa-bility of cationic Gemini surfactant for polyester fabric[J]. Guangdong Chemical Industry, 2012,38(18):6-7.
[15]	阎克路. 染整工艺原理:上册[M]. 北京: 中国纺织出版社, 2009:142.
	YAN Kelu. Principle of dyeing and finishing: I[M]. Beijing: China Textile & Apparel Press, 2009:142.
[16]	王宗舞, 刘伟, 陈玉行, 等. 碱减量对涤纶亲水性改性影响的研究[J]. 广东化工, 2018,44(13):133-143.
	WANG Zongwu, LIU Wei, CHEN Yuxing, et al. Rese-arch on effect of alkaline reduction on hydrophilic-ity modification of polyester[J]. Guangdong Chemical Industry, 2018,44(13):133-143.

相关文章 15

[1]	李瑞卿, 王伟, 魏炳举, 周长文, 张淑桃. 应用环保型还原剂的硫化黑染色工艺[J]. 纺织学报, 2020, 41(08): 50-54.
[2]	刘越, 莫林祥, 陈丰. 拼混型黑色分散染料的配伍性及其染色性能[J]. 纺织学报, 2019, 40(12): 63-67.
[3]	江华, 张志恒, 蔡金芳, 陈维国, 崔志华, 孙岩峰. 芳伯胺染料对蚕丝织物的重氮化-偶合染色及工艺调控[J]. 纺织学报, 2019, 40(11): 100-105.
[4]	林佳濛, 缪旭红, 万爱兰. 等离子体预处理对聚吡咯/涤纶经编导电织物结构和性能的影响[J]. 纺织学报, 2019, 40(09): 97-101.
[5]	韩虎, 李伟婷, 魏会芳, 王小艳, 孙昌, 许长海. 酸性染料易染氨纶的染色动力学[J]. 纺织学报, 2019, 40(08): 76-79.
[6]	尹思力, 杨洋, 江文, 石业新, 周小华, 黄金洪. 接枝蚕蛹肽羧基化粘胶纤维的制备及其优化工艺[J]. 纺织学报, 2019, 40(08): 14-19.
[7]	武奇奇, 李敏, 刘怡宁, 王乐军, 张丽平, 付少海. 聚乳酸织物载体染色性能[J]. 纺织学报, 2019, 40(01): 79-83.
[8]	曹意陈韶娟尹德河曹洪花马建伟. 碱溶性涤纶/锦纶6海岛纤维各组分性能解析[J]. 纺织学报, 2018, 39(09): 15-21.
[9]	梁静钟毅毛志平徐红张琳萍隋晓锋. 晶型对分散染料染色性能的影响[J]. 纺织学报, 2018, 39(07): 69-73.
[10]	陈永邦黄成阎克路叶敬平. 导湿排汗涤纶针织物的抗菌亲水整理[J]. 纺织学报, 2018, 39(05): 74-79.
[11]	李敏赵影张丽平张奕付少海. 涤纶针织物数码印花清晰度的影响因素[J]. 纺织学报, 2018, 39(05): 62-66.
[12]	姚萍江文王江黄金洪周小华. 接枝壳寡糖抗菌粘胶纤维的制备及其抗菌性与染色效果[J]. 纺织学报, 2018, 39(04): 9-13.
[13]	刘艳春白刚钱红飞. 聚酰亚胺织物的羧基化表面改性[J]. 纺织学报, 2018, 39(03): 103-107.
[14]	曹机良孟春丽曹毅闫凯吴宁杰王潮霞. 烷基咪唑类双子型离子液体对涤纶织物的碱减量处理[J]. 纺织学报, 2018, 39(01): 79-83.
[15]	俞俭王业师吕景春周天池魏取福. 低温等离子体处理木棉纤维的染色性能[J]. 纺织学报, 2017, 38(12): 88-94.

Metrics

Viewed

Full text

Abstract

Cited

Shared

Discussed

NaOH质量浓度/ (g·L^-1)	工艺	减量率/%
NaOH质量浓度/ (g·L^-1)	工艺	分散大红 HA-G	分散黄棕 H-2R	分散蓝 HA-RL
0.0	一浴一步法	0.00	0.00	0.00
	常规工艺	0.00	0.00	0.00
2.5	一浴一步法	3.91	4.13	3.80
	常规工艺	4.00	3.94	3.78
5.0	一浴一步法	8.10	8.56	8.93
	常规工艺	7.90	8.00	8.50
7.5	一浴一步法	14.42	14.61	14.92
	常规工艺	14.20	14.50	14.85
10.0	一浴一步法	20.36	20.10	20.23
	常规工艺	20.18	20.20	20.00

温度/℃	减量率/%
温度/℃	分散大红 HA-G	分散黄棕 H-2R	分散蓝 HA-RL
100	1.00	1.00	1.00
110	2.00	2.50	2.50
120	4.50	4.00	4.50
130	19.50	20.00	19.50

染料	减量率/%		K/S值		增深率/%		偏差S_λ
染料	不加碱	烧碱10 g/L	不加碱	烧碱10 g/L	增深率/%		不加碱		烧碱10 g/L
分散大红HA-G	0.00	21.43	20.60	23.41	13.59	0.018		0.006
分散黄棕H-2R	0.00	20.96	12.08	13.43	11.15	0.015		0.009
分散蓝HA-RL	0.00	20.32	25.14	27.41	9.42	0.018		0.010
三原色的拼色	0.00	21.06	29.36	32.46	10.55	0.016		0.008

染料	耐水洗色牢度							耐摩擦色牢度
	沾色						褪色	干摩擦		湿摩擦
	毛	腈	涤	锦	棉	醋酯	褪色	沾色	褪色	沾色	褪色
分散大红HA-G	5	5	4~5	4	5	4~5	5	4~5	5	4~5	5
分散黄棕H-2R	5	5	5	4~5	5	4~5	5	5	5	4~5	5
分散蓝HA-RL	4~5	5	5	4	5	4~5	5	4~5	5	4~5	4~5
三原色的拼色	4~5	5	4~5	4	5	4~5	4~5	5	5	4~5	5

染料	耐酸汗渍色牢度							耐碱汗渍色牢度
	沾色						褪色	沾色						褪色
	毛	腈	涤	锦	棉	醋酯	褪色	毛	腈	涤	锦	棉	醋酯	褪色
分散大红HA-G	5	4~5	5	4~5	4~5	4~5	4~5	5	4~5	5	5	4~5	4~5	4~5
分散黄棕H-2R	5	5	5	4~5	5	4~5	5	5	5	5	4~5	5	4~5	5
分散蓝HA-RL	5	5	5	4~5	4~5	4~5	5	5	4~5	5	5	4~5	5	4~5
三原色的拼色	5	4~5	5	5	4~5	5	4~5	5	4~5	5	5	4~5	5	4~5
