基于改进的加权中值滤波与K-means聚类的织物缺陷检测

张缓缓(), 马金秀, 景军锋, 李鹏飞

西安工程大学电子信息学院, 陕西西安 710048

收稿日期:2018-12-03 修回日期:2019-06-02 出版日期:2019-12-15 发布日期:2019-12-18
作者简介:张缓缓(1986—),女,讲师,硕士。主要研究方向为图像处理、模式识别。E-mail:zhanghuanhuan0557@163.com。
基金资助:
国家自然科学基金项目(61902302);陕西省高校科协青年人才托举计划项目(20180115);陕西省教育厅科研计划项目(18JK0338)

Fabric defect detection method based on improved fast weighted median filtering and K-means

ZHANG Huanhuan(), MA Jinxiu, JING Junfeng, LI Pengfei

School of Electronic and Information, Xi'an Polytechnic University, Xi'an, Shaanxi 710048, China

Received:2018-12-03 Revised:2019-06-02 Online:2019-12-15 Published:2019-12-18

摘要/Abstract

摘要：

为检测纹理织物在生产过程中产生的各种疵点,提出一种基于改进的加权中值滤波与K-means聚类相结合的纹理织物疵点检测方法。首先利用改进的加权中值滤波对纹理织物图像进行预处理,以减少纹理信息对疵点检测产生的影响,同时通过联合直方图动态数据分配权重和像素,减少寻求中位数的时间来有效地缩短检测时间,提高了执行速度;然后采用K-means算法对滤波后的织物图像进行聚类,计算织物图像疵点和非疵点的聚类中心,进而实现图像疵点区域的分割。实验结果表明,该方法可有效地检测出方格、点形、星形、平纹、斜纹等多类型纹理织物的疵点,并显著提高检测速度。

关键词: 织物疵点检测, 改进加权中值滤波, 联合直方图, K-means聚类

Abstract:

In order to detect various defects in the production process of textured fabrics, a texture fabric defect detection method based on improved weighted median filtering and K-means clustering was proposed. Firstly, the fabric image was preprocessed by the improved weighted median filter to reduce the influence of texture information on the defect detection. At the same time, by assigning weights and pixels to the histogram dynamic data, the time to seek the median was effectively shortened to increase the execution speed. Then, the K-means algorithm was adopted to cluster the filtered fabric images, and the cluster centers of the fabric image defects and non-defects were calculated, thereby realizing the segmentation of the image defect regions. The experimental results show that the method can effectively detect the defects of various types of textured fabrics such as square, dot, star, plain, and twill and significantly increase the detection speed.

Key words: fabric defect detection, improved weighted median filtering, joint histogram, K-means clustering

中图分类号:

TP391

张缓缓, 马金秀, 景军锋, 李鹏飞. 基于改进的加权中值滤波与K-means聚类的织物缺陷检测[J]. 纺织学报, 2019, 40(12): 50-56.

ZHANG Huanhuan, MA Jinxiu, JING Junfeng, LI Pengfei. Fabric defect detection method based on improved fast weighted median filtering and K-means[J]. Journal of Textile Research, 2019, 40(12): 50-56.
