高疏水染料结构对超高分子量聚乙烯纤维染色性能的影响

doi:10.13475/j.fzxb.20190800606

摘要/Abstract

摘要：

为解决超高分子量聚乙烯(UHMWPE)纤维难以上染的问题,筛选出结构平面性良好的高疏水染料对UHMWPE纤维进行染色。通过染色后纤维K/S值、染料与纤维的亲和力、分配系数、染色热和染色熵等热力学参数的测定,研究了高疏水染料结构中疏水基团数目及其链长、硝基等强极性基团对纤维染色性能的影响规律,并分析了染料溶解度参数对其与纤维染色性能之间的相关性。结果表明:高疏水染料对UHMWPE纤维染色可获得高表观深度;染料的疏水性及其溶解度参数是影响其对UHMWPE纤维染色性能的重要因素;就染料母体结构而言,偶氮结构较蒽醌结构对UHMWPE纤维易于获得良好的染色性能。

关键词: 超高分子量聚乙烯纤维, 高疏水染料, 染色热力学, 吸附等温线

Abstract:

In order to solve the dyeing problem of ultrahigh molecular weight polyethylene (UHMWPE) fibers, the dyes with extreme hydrophobicity and good planarity were selected. The influence of dye structure on dyeing properties of UHMWPE fibers was studied by the determination of the K/S value of dyed fibers and the thermodynamic parameters such as the affinity, the partition coefficient, enthalpy change and entropy change between dyes and fibers. The number and chain length of hydrophobic groups, the polar groups such as nitro group and solubility parameter of hydrophobic dyes were analyzed. The results show that extreme hydrophobic dyes have satisfactory color depth on UHMWPE fibers. The hydrophobicity and solubility parameter of dyes are important factors affecting the dyeing properties of UHMWPE fiber. Azo-structured dyes are easier to obtain better dyeing performance for UHMWPE fiber than anthraquinone-structured dyes.

Key words: ultrahigh molecular weight polyethylene fiber, extreme hydrophobic dye, dyeing thermodynamics, adsorption isotherm

中图分类号:

TQ624

王晓春, 张健飞, 张丽平, 王娜娜, 闫金龙, 赵国樑. 高疏水染料结构对超高分子量聚乙烯纤维染色性能的影响[J]. 纺织学报, 2020, 41(03): 78-83.

WANG Xiaochun, ZHANG Jianfei, ZHANG Liping, WANG Nana, YAN Jinlong, ZHAO Guoliang. Influence of extreme hydrophobic dye structure on dyeing properties of ultrahigh molecular weight polyethylene fibers[J]. Journal of Textile Research, 2020, 41(03): 78-83.

图/表 7

图1

表1

图2

图3

表2

表3

表4

参考文献 15

[1]	王晓春, 闫金龙, 张丽平, 等. 超高分子质量聚乙烯纤维分散染料染色性能[J]. 纺织学报, 2017,38(11):85-90.
	WANG Xiaochun, YAN Jinlong, ZHANG Liping, et al. Dyeing properties of ultrahigh molecular weight polyethylene fibers with disperse dye[J]. Journal of Textile Research, 2017,38(11):85-90.
[2]	王晓春, 张健飞, 刘铭, 等. 熔纺 UHMWPE/聚烯烃纤维的原液着色[J]. 北京服装学院学报, 2019,39(1):28-32.
	WANG Xiaochun, ZHANG Jianfei, LIU Ming, et al. Study on dope dyeing of UHMWPE /Polyolefin fiber by melt spinning[J]. Journal of Beijing Institute of Clothing Technology, 2019,39(1):28-32.
[3]	闫金龙, 张丽平, 王晓春, 等. 超高分子量聚乙烯纤维染色研究进展[J]. 纺织导报, 2016(6):84-86.
	YAN Jinlong, ZHANG Liping, WANG Xiaochun, et al. Research progress in dyeing process of UHMWPE fiber[J]. China Textile Leader, 2016(6):84-86.
[4]	杭州翔盛高强纤维材料股份有限公司. 一种超高分子量聚乙烯纤维有机颜料分散锚固原液着色方法:ZL103572397A[P]. 2014-01-12.
	Hangzhou Xiangsheng High Strength Fiber Materials Co., Ltd. Organic pigment dispersing and anchoring dope dyeing method for ultra-high molecular weight polyethylene fiber: ZL103572397A[P]. 2014-01-12.
[5]	浙江金昊特种纤维有限公司. 超高分子量聚乙烯有色细旦纤维的生产方法: ZL101718003A[P]. 2010-06-02.
	Zhejiang Jinhao Special Fiber Co., Ltd. Method for producing ultra-high molecular weight polyethylene colored fine denier fiber: ZL101718003A[P]. 2010-06-02.
[6]	顾群, 王宗宝, 王剑, 等. 一种超高分子量聚乙烯有色纤维的制备方法:ZL103866416A[P]. 2016-04-18.
	GU Qun, WANG Zongbao, WANG Jian, et al. Preparation method for ultra-high molecular weight polyethylene colored fibers: ZL103866416A[P]. 2014-06-18.
[7]	绍兴金渔纺织新技术有限公司. 有色超高分子量聚乙烯纤维的制备方法: ZL103046403A[P]. 2013-04-17.
	Shaoxing Jinyu Textile New Technology Co., Ltd. Method for preparing colored UHMW (ultra-high molecular weight) polyethylene fibers: ZL103046403A[P]. 2013-04-17.
[8]	杭州祥盛高强纤维材料股份有限公司. 一种超高分子量聚乙烯纤维染色装置及其方法:ZL102953186A[P]. 2013-03-06.
	Hangzhou Xiangsheng High Strength Fiber Material Co., Ltd. Ultra high molecular weight polyethylene fiber dyeing device and method: ZL102953186A[P]. 2013-03-06.
[9]	北京同益中特种纤维技术开发有限公司, 中纺投资发展股份有限公司. 一种超高分子量聚乙烯纤维的染色方法: ZL103711007A[P]. 2014-04-09.
	Beijing Tongyizhong Specialty Fiber Technology Dev.Co., Ltd,Sinotex Invest & Dev Co., Ltd. Dyeing method for ultrahigh molecular weight polyethylene fibers: ZL103711007A[P]. 2014-04-09.
[10]	KIM Taekyeong, JEON Seonhee. Coloration of ultrahigh molecular weight polyethylene fibers using alkyl-substituted monoazo yellow and red dyes[J]. Fibers and Polymers, 2013,14(1):105-109.
[11]	BAE Jinseok, KIM Taekyeong, LEE Changwhan. Synjournal of novel violet dyes for polyolefin fibers using N,N-dihexyl-2-methoxy-5-methylaniline and various diazo components[J]. Fibers and Polymers, 2014,15(12):248-253.
[12]	MARYAM Ataeefard, MAJID Mohseni, SIAMAK Moradian. Polypropylene/clay nanacomposite: kinetic and nanacomposite: kinetic and thermodynamic of dyeing with various disperse dyes[J]. Journal of The Textile Institute, 2016,107(2):182-190.
[13]	陈荣圻. 溶解度参数在分散染料拼混染色中的应用[J]. 染整技术, 2018,40(10):1-5.
	CHEN Rongqi. Applications of solubility parameter in combination dyeing of disperse dye (continued one)[J]. Textile Dyeing and Finishing Journal, 2018,40(10):1-5.
[14]	陈荣圻. 溶解度参数在聚酯类纤维分散染色中的应用:二[J]. 印染, 2013(6):49-54.
	CHEN Rongqi. Application of solubility parameter to disperse dyeing of polyester fibers:Ⅱ[J]. China Dyeing & Finishing, 2013(6):49-54.
[15]	刘思俊. 超高分子量聚乙烯相分离及微孔膜制备的研究[D]. 上海:上海交通大学, 2013: 30.
	LIU Sijun. Study on phase separation and membrane preparation of ultra-high molecular weight poly-ethylene[D]. Shanghai:Shanghai Jiaotong University, 2013: 30.

相关文章 15

[1]	展晓晴, 李凤艳, 赵健, 李海琼. 超高分子量聚乙烯纤维的热力学稳定性能[J]. 纺织学报, 2020, 41(08): 9-14.
[2]	吴利伟, 王伟, 林佳弘, 姜茜. 芳纶/超高分子量聚乙烯织物增强聚氨酯夹芯复合材料制备及其力学性能[J]. 纺织学报, 2019, 40(07): 64-70.
[3]	杨海伟王宗乾徐晶晶王明荣王邓峰. 蚕丝丝素酪氨酸残基的偶合修饰与工艺调控[J]. 纺织学报, 2018, 39(09): 102-108.
[4]	张恒甄琪钱晓明刘让同张一风. 仿生树型超高分子量聚乙烯柔性防刺复合材料制备及其透湿性能[J]. 纺织学报, 2018, 39(04): 63-68.
[5]	刘铭张丽平张敏王晓春赵国樑王轩唐星辰杨中开. 铁黄颜料的表面改性及其在超高分子量聚乙烯中的应用[J]. 纺织学报, 2018, 39(02): 86-90.
[6]	高慧英蒙冉菊华佳瑞邵碧琼刘琳姚菊明. 改性废棉对水溶液中Cu2+的吸附性能[J]. 纺织学报, 2017, 38(12): 112-118.
[7]	王梦琴王树根. 棉纤维阳离子化的简易定量检测方法[J]. 纺织学报, 2016, 37(4): 75-79.
[8]	洪剑寒潘志娟李敏姚穆. 氧气等离子体预处理对UHMWPE/PANI复合纤维导电性能的影响[J]. 纺织学报, 2013, 34(6): 1-7.
[9]	王晓宋志云郝军黄成徐明媚. 紫外光接枝丙烯酸亚麻织物阳离子染料染色热力学[J]. 纺织学报, 2012, 33(12): 49-52.
[10]	李丹，董锁拽，翁伟明，周文龙. 蚕丝纤维吸附辛基酚聚氧乙烯醚的动力学研究[J]. 纺织学报, 2011, 32(9): 64-68.
[11]	杜旭宜;郑今欢;申屠艳艳;娄涛. 苯甲醇对腈纶纤维阳离子染料染色的作用机制[J]. 纺织学报, 2011, 32(5): 80-85.
[12]	丁飞飞;汪澜;林俊雄. 低熔点皮芯复合纤维分散染料染色机制[J]. 纺织学报, 2011, 32(1): 67-72.
[13]	尤秀兰;胡盼盼;刘兆峰. 高强有机合成纤维的结构形成[J]. 纺织学报, 2010, 31(5): 146-152.
[14]	王旭;晏雄. 聚乙烯自增强复合材料损伤行为的声发射特征[J]. 纺织学报, 2010, 31(3): 27-31.
[15]	项伟;蔡再生. 桑蚕丝织物酸性染料清洁染色工艺[J]. 纺织学报, 2010, 31(11): 77-82.

Metrics

Viewed

Full text

Abstract

Cited

Shared

Discussed

染料	K/S值	耐摩擦牢度/级
染料	K/S值	干	湿
乙基黄	11.6	4~5	4~5
苏丹蓝Ⅱ	4.0	3	3~4
油红O	13.7	3	3~4
分散红1	0.7	2~3	3
分散蓝291	0.9	2	2~3
分散橙25	0.4	2~3	2~3

序号	染料	K/S值	分配系数K	-Δμ⁰/ (kJ·mol^-1)	偶极矩/ D	摩尔体积/ (cm³·mol^-1)
1	乙基黄	11.6	5.35	-5.55	4.124 7	179.935
2	苏丹黄Ⅰ	4.8	9.56	-7.47	2.013 1	168.467
3	苏丹红G	3.4	6.22	-6.05	2.276 6	205.009
4	苏丹红Ⅲ	3.1	16.35	-9.25	2.498 9	278.365
5	苏丹红Ⅳ	5.3	17.73	-9.51	3.112 6	243.503
6	苏丹红B	10.2	29.26	-11.17	1.824 3	264.291
7	油红O	13.7	107.50	-15.48	2.920 2	290.521
8	蒽醌蓝	0.9	2.16	-2.55	3.039 7	184.899
9	苏丹蓝Ⅱ	4.0	22.46	-10.30	3.163 6	304.766
10	分散橙25	0.4	0.93	-0.25	8.523 5	260.539

染料	分配系数K		-Δμ⁰/(kJ·mol^-1)		染色热 ΔH⁰/(kJ·mol^-1)	染色熵ΔS⁰/(kJ·mol^-1·K^-1)
染料	100 ℃	125 ℃	100 ℃	125 ℃	染色热 ΔH⁰/(kJ·mol^-1)	100 ℃	125 ℃
乙基黄	3.55	5.35	-4.19	-5.55	-27.10	-0.09	-0.08
蒽醌蓝	0.62	2.16	-1.56	-2.55	-34.36	-0.10	-0.09
苏丹蓝Ⅱ	10.17	22.46	-7.68	-10.30	-87.61	-0.26	-0.25
苏丹红Ⅲ	9.32	16.35	-7.39	-9.25	-60.15	-0.19	-0.17
苏丹红Ⅳ	9.64	17.13	-7.50	-9.51	-65.57	-0.20	-0.19
苏丹红B	8.28	29.26	-6.99	-11.17	-144.64	-0.42	-0.39
油红O	28.24	107.50	-11.05	-15.48	-149.49	-0.44	-0.41

序号	染料	溶解度参数	K/S值
1	乙基黄	8.24	11.6
2	苏丹黄	8.57	4.8
3	苏丹红Ⅲ	8.43	3.1
4	苏丹红Ⅳ	8.52	5.3
5	苏丹红B	8.51	10.2
6	油红O	8.54	13.7
7	蒽醌蓝	9.94	0.9
8	苏丹蓝Ⅱ	9.43	4.0
9	分散红1	9.76	0.7
10	分散蓝291	10.89	0.9
11	分散橙25	9.88	0.4
