环锭纺纱信息物理生产系统建模方法

doi:10.13475/j.fzxb.20201007809

纺织学报 ›› 2021, Vol. 42 ›› Issue (02): 65-73.doi: 10.13475/j.fzxb.20201007809

环锭纺纱信息物理生产系统建模方法

殷士勇¹^,², 鲍劲松²(), 唐仕喜¹, 杨芸²

1.盐城师范学院信息工程学院, 江苏盐城 224002
2.东华大学机械工程学院, 上海 201620

收稿日期:2020-10-29 修回日期:2020-11-21 出版日期:2021-02-15 发布日期:2021-02-23
通讯作者: 鲍劲松
作者简介:殷士勇(1979—),男,副教授,博士。主要研究方向为智能制造与测控、纺纱信息物理生产系统。
基金资助:
国家重点研发计划资助项目(2017YFB1304000);工信部智能制造综合标准与新模式应用项目(工信厅装函)([2018]265号)

Modeling method of cyber physical production system for ring spinning

YIN Shiyong¹^,², BAO Jinsong²(), TANG Shixi¹, YANG Yun²

1. School of Information Engineering, Yancheng Teachers University, Yancheng, Jiangsu 224002, China
2. College of Mechanical Engineering, Donghua University, Shanghai 201620, China

Received:2020-10-29 Revised:2020-11-21 Online:2021-02-15 Published:2021-02-23
Contact: BAO Jinsong

摘要/Abstract

摘要：

针对环锭纺纱工艺流程长、纤维形态变化大、生产连续性与离散性混合,生产过程中数据流和控制流的关系多样复杂等问题,深入研究了环锭纺纱信息物理生产系统构架。先根据信息物理系统的“计算、通信、控制”特征,定义了环锭纺纱信息物理生产系统;在此基础上分析了环锭纺纱信息物理生产系统的纤维流、数据流和控制流,提出“纤维流-数据流-控制流”融合的环锭纺纱信息物理生产系统模型。然后,基于模型的系统工程方法,采用SysML建模语言建立环锭纺纱信息物理生产系统需求和局部用例模型以及对“纤维流-数据流-控制流”融合建模。研究结果表明,提出的建模方法能有效建立环锭纺纱信息物理生产系统模型,并对环锭纺纱生产智能化具有一定的借鉴意义。

关键词: 环锭纺纱, 信息物理生产系统, 纤维流, 数据流, 控制流, 纺织生产智能化

Abstract:

In light of the problems such as long process flow of ring spinning, large variations in fiber morphology, mixed production continuity and discreteness, and the diverse and complex relationships between data flow and control flow in the production process, the ring spinning cyber physical production system architecture was comprehensively studied. According to the "computation, communication, and control" characteristics of cyber physical systems, the ring spinning cyber physical production system was defined. On this basis, the fiber flow, data flow and control flow of ring spinning cyber physical production were analyzed, leading to the establishment of a ring spinning cyber-physical production system model encompassing "fiber flow-data flow-control flow". Using the model-based system engineering method, the SysML modeling language was used to specify requirements for the partial models and full model for the ring spinning cyber physical production system considering "fiber flow-data flow-control flow". The results show that the proposed modeling method can effectively establish a ring spinning cyber physical production system model, and has certain reference significance for the intelligent production of ring spinning.

Key words: ring spinning, cyber physical production system, fiber flow, data flow, control flow, intelligent textile production

中图分类号:

TS101.8

殷士勇, 鲍劲松, 唐仕喜, 杨芸. 环锭纺纱信息物理生产系统建模方法[J]. 纺织学报, 2021, 42(02): 65-73.

YIN Shiyong, BAO Jinsong, TANG Shixi, YANG Yun. Modeling method of cyber physical production system for ring spinning[J]. Journal of Textile Research, 2021, 42(02): 65-73.
