静电纺短纤维的制备及其生物医学应用

doi:10.13475/j.fzxb.20210106008

摘要/Abstract

摘要：

传统静电纺纳米纤维常作为组织工程支架被用于修复缺损部位,往往必须借助外科手术有创植入,极大限制了其在生物医学领域中的应用。为促进静电纺丝技术的开发和应用,综述了静电纺短纤维的制备及其功能化的方法,分类介绍了功能化短纤维在诊断检测、治疗和组织工程这3个方面的生物医学应用;系统分析通过调节工艺参数、后续加工等方式保留静电纺纳米纤维膜的内在功能,以及基于其小尺寸和单分散性,避免纤维膜植入所造成的机体侵入创伤;最后,结合静电纺短纤维当前发展情形分析了其在生物医学领域应用中所面临的挑战和未来的发展前景。

关键词: 静电纺丝, 纳米纤维, 功能化短纤维, 诊断检测, 肿瘤治疗, 组织工程

Abstract:

Traditional electrospun nanofibers are often used as tissue engineering scaffolds to repair defects, which often need invasive implantation by surgery, greatly limiting their applications in biomedical fields. In order to promote the development and applications of electrospinning technology, this paper reviewed the preparation and functionalization methods of electrospun short fibers, the biomedical applications of functional short fiber in diagnosis and therapy, and tissue engineering. Electrospun short fibers have received great attention and can be prepared by adjusting process parameters and subsequent processing. Electrospun short fibers retain their intrinsic functions of electrospun nanofiber membranes, they can avoid the invasion and trauma caused by the implantation of fiber membranes because of their small size and monodispersity. The challenges and future development prospects of electrospun short fibers in biomedical fields were also analyzed.

Key words: electrospinning, nanofiber, functional short fiber, diagnostic testing, tumor therapy, tissue engineering

中图分类号:

TS101

张蓓蕾, 沈明武, 史向阳. 静电纺短纤维的制备及其生物医学应用[J]. 纺织学报, 2021, 42(05): 1-8.

ZHANG Beilei, SHEN Mingwu, SHI Xiangyang. Preparation and biomedical applications of electrospun short fibers[J]. Journal of Textile Research, 2021, 42(05): 1-8.

图/表 2

表1

图1

参考文献 43

[1]	SILL T J, VON RECUM H A. Electrospinning: applications in drug delivery and tissue engineering[J]. Biomaterials, 2008,29(13):1989-2006. doi: 10.1016/j.biomaterials.2008.01.011
[2]	LI D, XIA Y. Electrospinning of nanofibers: reinventing the wheel?[J]. Adv Mater, 2004,16(14):1151-1170. doi: 10.1002/(ISSN)1521-4095
[3]	XUE J, WU T, DAI Y, et al. Electrospinning and electrospun nanofibers: methods, materials, and applications[J]. Chem Rev, 2019,119(8):5298-5415. doi: 10.1021/acs.chemrev.8b00593
[4]	ZHAO J, CUI W. Functional electrospun fibers for local therapy of cancer[J]. Adv Fiber Mater, 2020,2(5):229-245. doi: 10.1007/s42765-020-00053-9
[5]	HUANG W, XIAO Y, SHI X. Construction of electrospun organic/inorganic hybrid nanofibers for drug delivery and tissue engineering applications[J]. Adv Fiber Mater, 2019,1:32-45. doi: 10.1007/s42765-019-00007-w
[6]	HU J, KAI D, YE H, et al. Electrospinning of poly(glycerol sebacate)-based nanofibers for nerve tissue engineering[J]. Mater Sci Eng C-Mater Biol Appl, 2017,70:1089-1094. doi: 10.1016/j.msec.2016.03.035
[7]	QIU Q, WU J, QUAN Z, et al. Electrospun nanofibers of polyelectrolyte-surfactant complexes for antibacterial wound dressing application[J]. Soft Matter, 2019,15(48):10020-10028. doi: 10.1039/C9SM02043H
[8]	ZHAO Y L, FAN Z Y, SHEN M W, et al. Hyaluronic acid-Functionalized electrospun polyvinyl alcohol/polyethyleneimine nanofibers for cancer cell capture applications[J]. Adv Mater Interfaces, 2015,2(15):1500256. doi: 10.1002/admi.201500256
[9]	MA B, XIE J, JIANG J, et al. Rational design of nanofiber scaffolds for orthopedic tissue repair and regeneration[J]. Nanomedicine, 2013,8(9):1459-1481. doi: 10.2217/nnm.13.132
[10]	ZHANG H, LIU Y, CHEN M, et al. Shape effects of electrospun fiber rods on the tissue distribution and antitumor efficacy[J]. J Controlled Release, 2016,244:52-62. doi: 10.1016/j.jconrel.2016.05.011
[11]	WENG L, BODA S K, WANG H, et al. Novel 3D hybrid nanofiber aerogels coupled with BMP-2 peptides for cranial bone regeneration[J]. Adv Healthcare Mater, 2018,7(10):1701415. doi: 10.1002/adhm.v7.10
[12]	WEI J, XIA T, CHEN W, et al. Glucose and lipid metabolism screening models of hepatocyte spheroids after culture with injectable fiber fragments[J]. J Tissue Eng Regen Med, 2020,14(6):774-788. doi: 10.1002/term.v14.6
[13]	SCHOLTEN E, DHAMANKAR H, BROMBERG L, et al. Electrospray as a tool for drug micro-and nanoparticle patterning[J]. Langmuir, 2011,27(11):6683-6688. doi: 10.1021/la201065n
[14]	FATHONA I W, YABUKI A. A simple one-step fabrication of short polymer nanofibers via electrospinning[J]. J Mater Sci, 2014,49(9):3519-3528. doi: 10.1007/s10853-014-8065-y
[15]	LUO C J, STRIDE E, STOYANOV S, et al. Electrospinning short polymer micro-fibres with average aspect ratios in the range of 10-200[J]. J Polym Res, 2011,18(6):2515-2522. doi: 10.1007/s10965-011-9667-6
[16]	LI P, XI Y, LI K, et al. Fabrication and properties of electrospun magnetoelectric graphene/Fe₃O₄/poly(lactic-co-glycolic acid) short nanofibers[J]. J Nanosci Nanotechnol, 2019,19(1):170-175. doi: 10.1166/jnn.2019.16400
[17]	LI Y, CAO L, YIN X, et al. Semi-interpenetrating polymer network biomimetic structure enables superelastic and thermostable nanofibrous aerogels for cascade filtration of PM_2.5[J]. Adv Funct Mater, 2020,30(14):1910426. doi: 10.1002/adfm.v30.14
[18]	YOSHIKAWA C, ZHANG K, ZAWADZAK E, et al. A novel shortened electrospun nanofiber modified with a concentrated polymer brush[J]. Sci Technol Adv Mater, 2019,12(1):015003. doi: 10.1088/1468-6996/12/1/015003
[19]	BODA S K, CHEN S, CHU K, et al. Electrospraying electrospun nanofiber segments into injectable microspheres for potential cell delivery[J]. ACS Appl Mater Interfaces, 2018,10(30):25069-25079. doi: 10.1021/acsami.8b06386
[20]	SAWAWI M, WANG T Y, NISBET D R, et al. Scission of electrospun polymer fibres by ultrasonication[J]. Polymer, 2013,54(16):4237-4252. doi: 10.1016/j.polymer.2013.05.060
[21]	FRIEDEMANN K, CORRALES T, KAPPL M, et al. Facile and large-scale fabrication of anisometric particles from fibers synthesized by colloid-electrospinning[J]. Small, 2012,8(1):144-153. doi: 10.1002/smll.201101247
[22]	LI H, WAN H, XIA T, et al. Therapeutic angiogenesis in ischemic muscles after local injection of fragmented fibers with loaded traditional Chinese medicine[J]. Nanoscale, 2015,7(30):13075-13087. doi: 10.1039/C5NR02005K
[23]	WEI J, LEI D, CHEN M, et al. Engineering HepG2 spheroids with injectable fiber fragments as predictable models for drug metabolism and tumor infiltration[J]. J Biomed Mater Res Part B, 2020,108(8):3331-3344. doi: 10.1002/jbm.b.v108.8
[24]	OMIDINIA-ANARKOLI A, BOESVELD S, TUVSHINDORJ U, et al. An injectable hybrid hydrogel with oriented short fibers induces unidirectional growth of functional nerve cells[J]. Small, 2017,13(36):1702207. doi: 10.1002/smll.v13.36
[25]	JOHN J V, CHOKSI M, CHEN S, et al. Tethering peptides onto biomimetic and injectable nanofiber microspheres to direct cellular response[J]. Nanomedicine, 2019,22:102081.
[26]	FENG Z Q, SHI C, ZHAO B, et al. Magnetic electrospun short nanofibers wrapped graphene oxide as a promising biomaterials for guiding cellular behavior[J]. Mater Sci Eng C-Mater Biol Appl, 2017,81:314-320. doi: 10.1016/j.msec.2017.08.015
[27]	WEI J, LUO X, CHEN M, et al. Spatial distribution and antitumor activities after intratumoral injection of fragmented fibers with loaded hydroxycamptothecin[J]. Acta Biomater, 2015,23:189-200. doi: 10.1016/j.actbio.2015.05.020
[28]	HE N, CHEN Z, YUAN J, et al. Tumor pH-Responsive release of drug-conjugated micelles from fiber fragments for intratumoral chemotherapy[J]. ACS Appl Mater Interfaces, 2017,9(38):32534-32544. doi: 10.1021/acsami.7b09519
[29]	CHEN Z, LIU W, ZHAO L, et al. Acid-labile degradation of injectable fiber fragments to release bioreducible micelles for targeted cancer therapy[J]. Biomacromolecules, 2018,19(4):1100-1110. doi: 10.1021/acs.biomac.7b01696
[30]	WANG T Y, BRUGGEMAN K F, KAUHAUSEN J A, et al. Functionalized composite scaffolds improve the engraftment of transplanted dopaminergic progenitors in a mouse model of Parkinson's disease[J]. Biomaterials, 2016,74:89-98. doi: 10.1016/j.biomaterials.2015.09.039
[31]	XIAO Y, LIN L, SHEN M, et al. Design of DNA aptamer-functionalized magnetic short nanofibers for efficient capture and release of circulating tumor cells[J]. Bioconjugate Chem, 2020,31(1):130-138. doi: 10.1021/acs.bioconjchem.9b00816
[32]	ZHAO Y L, JIE X, SHI X Y, et al. Capturing cancer cells using hyaluronic acid-immobilized electrospun random or aligned PLA nanofibers[J]. Colloid Surf A-Physicochem Eng Asp, 2019,583:123978. doi: 10.1016/j.colsurfa.2019.123978
[33]	FEHM T, MULLER V, ALIX-PANABIERES C, et al. Micrometastatic spread in breast cancer: detection, molecular characterization and clinical relevance[J]. Breast Cancer Res, 2008,10(S1):1-10.
[34]	YOON H J, SHANKER A, WANG Y, et al. Tunable thermal-sensitive polymer-graphene oxide composite for efficient capture and release of viable circulating tumor cells[J]. Adv Mater, 2016,28(24):4891-4897. doi: 10.1002/adma.v28.24
[35]	LEE A W, LIN F X, WEI P L, et al. Binary-blend fibber-based capture assay of circulating tumor cells for clinical diagnosis of colorectal cancer[J]. J Nanobiotechnol, 2018,16:4. doi: 10.1186/s12951-017-0330-1
[36]	LIU H, SUN N, DING P, et al. Fabrication of aptamer modified TiO₂ nanofibers for specific capture of circulating tumor cells[J]. Colloid Surf B-Biointerfaces, 2020,191:110985. doi: 10.1016/j.colsurfb.2020.110985
[37]	FAN Z Y, ZHAO Y L, ZHU X Y, et al. Folic acid modified electrospun poly(vinyl alcohol)/polyethyleneimine nanofibers for cancer cell capture applications[J]. Chin J Polym Sci, 2016,34(6):755-765. doi: 10.1007/s10118-016-1792-6
[38]	YANG G, LI X, HE Y, et al. Capturing circulating tumor cells through a combination of hierarchical nanotopography and surface chemistry[J]. ACS Biomater Sci Eng, 2018,4(6):2081-2088. doi: 10.1021/acsbiomaterials.7b00683
[39]	HE P, LI Y, HUANG Z, et al. A mu.pngunctional coaxial fiber membrane loaded with dual drugs for guided tissue regeneration[J]. J Biomater Appl, 2020,34(8):1041-1051. doi: 10.1177/0885328219894001
[40]	XIE Z, PARAS C B, WENG H, et al. Dual growth factor releasing multi-functional nanofibers for wound healing[J]. Acta Biomater, 2013,9(12):9351-9359. doi: 10.1016/j.actbio.2013.07.030
[41]	HE P, ZHONG Q, GE Y, et al. Dual drug loaded coaxial electrospun PLGA/PVP fiber for guided tissue regeneration under control of infection[J]. Mater Sci Eng C-Mater Biol Appl, 2018,90:549-556. doi: 10.1016/j.msec.2018.04.014
[42]	BODA S K, WANG H J, JOHN J V, et al. Dual delivery of alendronate and E7-BMP-2 peptide via calcium chelation to mineralized nanofiber fragments for alveolar bone regeneration[J]. ACS Biomater Sci Eng, 2020,6(4):2368-2375. doi: 10.1021/acsbiomaterials.0c00145
[43]	YU H, CHEN X J, CAI J, et al. Novel porous three-dimensional nanofibrous scaffolds for accelerating wound healing[J]. Chem Eng J, 2019,369:253-262. doi: 10.1016/j.cej.2019.03.091

Metrics

Viewed

Full text

Abstract

Cited

Shared

Discussed

基底聚合物纤维	制备方法	功能物质	功能化方法	功能	参考文献
PLGA	冷冻切片	SPION	物理掺杂	磁响应,指导细胞行为	[24]
PAN	均质处理	Fe₃O₄纳米颗粒、GO	物理掺杂	提高生物安全性,指导细胞行为	[26]
BG	超声破碎	Sr(NO₃)₂、CuCl₂	物理掺杂	促进新骨和血管生成	[11]
PELA	冷冻切片	HCPT	物理掺杂	抗肿瘤(化疗)	[27]
CDM/PELA	冷冻切片	PM_CPT	物理掺杂	抗肿瘤(靶向识别和还原刺激响应)	[28]
PLA-cdm	冷冻切片	PM_CPT	化学键合	抗肿瘤(靶向识别和还原刺激响应)	[29]
PLLA	冷冻切片	GDNF	化学键合	促进细胞存活和轴突生长	[30]
PEI/PVA	均质处理	Fe₃O₄@PEI、 DNA适配体	综合改性	捕获和分离CTCs	[31]
PCL/gelatin	冷冻切片、超声破碎	GelMA、BMP-2、QK	综合改性	促进新骨和血管生成	[25]
