聚对苯二甲酸乙二醇酯/SrAl2O4:Eu2+,Dy3+含杂纤维醇解及其回收产物性能

doi:10.13475/j.fzxb.20220704611

纺织学报 ›› 2023, Vol. 44 ›› Issue (02): 44-54.doi: 10.13475/j.fzxb.20220704611

聚对苯二甲酸乙二醇酯/SrAl₂O₄:Eu²⁺,Dy³⁺含杂纤维醇解及其回收产物性能

廖云珍¹^,², 朱亚楠¹^,²(), 葛明桥¹^,², 孙同明³, 张欣宇³

1.江南大学纺织科学与工程学院, 江苏无锡 214122
2.生态纺织教育部重点实验室(江南大学),江苏无锡 214122
3.国家先进印染技术创新中心, 山东泰安 271000

收稿日期:2022-07-14 修回日期:2022-11-12 出版日期:2023-02-15 发布日期:2023-03-07
通讯作者: 朱亚楠(1987—),男,副教授,博士。研究方向为功能性纤维制造理论与技术。E-mail:zhuyanan@jiangnan.edu.cn。
作者简介:廖云珍(1998—),女,硕士生。主要研究方向为废弃纤维降解及资源化利用。
基金资助:
国家先进印染技术创新中心科研基金项目(2022GCJJ20)

Alcoholysis and product recovery properties of polyethylene terephthalate/ SrAl₂O₄:Eu²⁺, Dy³⁺ hybrid fibers

LIAO Yunzhen¹^,², ZHU Ya'nan¹^,²(), GE Mingqiao¹^,², SUN Tongming³, ZHANG Xinyu³

1. College of Textile Science and Engineering, Jiangnan University, Wuxi, Jiangsu 214122, China
2. Key Laboratory of Eco-Textiles(Jiangnan University), Ministry of Education, Wuxi, Jiangsu 214122, China
3. National Innovation Center of Advanced Dyeing & Finishing Technology, Taian, Shandong 271000, China

Received:2022-07-14 Revised:2022-11-12 Published:2023-02-15 Online:2023-03-07

摘要/Abstract

摘要：

为提高废弃含杂纤维的回收率,以废弃的聚对苯二甲酸乙二醇酯基含杂纤维(PET/SrAl₂O₄:Eu²⁺,Dy³⁺)为研究对象,采用乙二醇醇解联合热乙醇的方法,探究含杂纤维的醇解性能并回收发光材料SrAl₂O₄:Eu²⁺,Dy³⁺及PET醇解产物对苯二甲酸双羟乙酯。通过改变乙二醇用量、反应温度及反应时间探讨乙二醇醇解条件对产物性能的影响,借助扫描电子显微镜、X射线衍射仪、差示扫描量热仪、分光光度测色仪、长余辉亮度仪等对醇解产物的微观形貌、物相结构、热稳定性能、余辉性能等进行测试与表征。结果表明:乙二醇用量、反应温度、反应时间和催化剂用量均不会改变发光材料SrAl₂O₄:Eu²⁺,Dy³⁺的物相结构;当反应温度为190 ℃,反应时间为180 min时,含杂纤维的醇解率达到100%,此时SrAl₂O₄:Eu²⁺,Dy³⁺的回收率为93%,初始亮度为3.906 cd/m², 对苯二甲酸双羟乙酯的回收率为82%。

关键词: 聚对苯二甲酸乙二醇酯, 含杂纤维, 醇解, 产物回收, 发光材料, 功能材料

Abstract:

Objective At present, the functional fibers containing various impurities are treated by landfill or incineration, which will not only affect the environment, but also cause the waste of functional materials. Some efforts have been made to recover waste luminescent fibers(polyethylene terephthalate(PET)/SrAl₂O₄:Eu²⁺,Dy³⁺), but the luminescent materials mixed in them are significantly affected by the violent reaction process. How to use a gentle way to complete the reaction and at the same time to ensure the consistency of functional materials is now the problem to be solved.
Method The waste PET/SrAl₂O₄:Eu²⁺,Dy³⁺ was used as the research object through combining ethylene glycol with hot ethanol, in order to recover the luminescent material SrAl₂O₄:Eu²⁺,Dy³⁺ and the alcoholysis product of PET. Different dosage of ethylene glycol were used to study the influence on the reaction temperature and reaction time of products, with the aid of scanning electron microscope, X-ray diffractometer, differential scanning calorimeter instrument, spectrophotometric color measurement instrument, the long afterglow brightness meter to analyze the microscopic morphology, phase structure, thermal stability, persistence, performance testing and characterization.
Results Both reaction temperature and reaction time had significant effects on the rate of alcoholysis and product recovery of PET/SrAl₂O₄:Eu²⁺,Dy³⁺. Under the condition where reaction time was 180 min and the reaction temperature was 190 ℃, the alcoholysis efficiency of PET/SrAl₂O₄:Eu²⁺,Dy³⁺ reached 100% and the recovery rate of the alcoholysis product reached 82%. However, the luminescence of SrAl₂O₄:Eu²⁺,Dy³⁺ was found seriously damaged under the same condition. At 180 ℃ and 180 min, the alcoholysis efficiency of PET/SrAl₂O₄:Eu²⁺,Dy³⁺ was 100%, and the recovery rate of the alcoholysis product was lower than that at 190 ℃, but the luminescence performance of SrAl₂O₄:Eu²⁺,Dy³⁺ was significantly improved. It is also discovered that the appropriate amount of ethylene glycol was able to promote the alcoholysis reaction, and the excessive amount of ethylene glycol can also inhibit the alcoholysis of PET/SrAl₂O₄:Eu²⁺,Dy³⁺. The investigation indicated that ethylene glycol and hot ethanol washing would not change the luminescence performance of the SrAl₂O₄:Eu²⁺,Dy³⁺, and the alcoholysis product was bis-hydroxyethyl terephthalate with high purity. Through the analysis of experimental data, it was found that ethylene glycol combined with hot ethanol is able to reduce the reaction time and reaction temperature required for the alcoholysis reaction, and improves the luminescence performance of the recovered SrAl₂O₄:Eu²⁺,Dy³⁺ and the recovery rate of the alcoholysis products.
Conclusion This research took waste PET/SrAl₂O₄:Eu²⁺,Dy³⁺ as the research object, ethylene glycol, hot ethanol and zinc acetate as raw materials, to optimize the alcoholics process for effective recovery of luminescent materials SrAl₂O₄:Eu²⁺,Dy³⁺ and PET alcoholysis products, and the performance of the recovery products were studied. The results provide a theoretical basis for the green recycling of waste mixed fibers and the recovery of functional materials.

Key words: polyethylene terephthalate, hybrid fiber, alcoholysis, product recovery, luminescent material, functional material

中图分类号:

TQ342.21

廖云珍, 朱亚楠, 葛明桥, 孙同明, 张欣宇. 聚对苯二甲酸乙二醇酯/SrAl₂O₄:Eu²⁺,Dy³⁺含杂纤维醇解及其回收产物性能[J]. 纺织学报, 2023, 44(02): 44-54.

LIAO Yunzhen, ZHU Ya'nan, GE Mingqiao, SUN Tongming, ZHANG Xinyu. Alcoholysis and product recovery properties of polyethylene terephthalate/ SrAl₂O₄:Eu²⁺, Dy³⁺ hybrid fibers[J]. Journal of Textile Research, 2023, 44(02): 44-54.

图/表 11

图1

图2

图3

图4

图5

图6

图7

图8

图9

图10

图11

参考文献 33

[1]	DAMAYANTI Damayanti, et al. WULANDARI Latasya Adelia, BAGASKORO Adhano,Possibility routes for textile recycling technology[J]. Polymers, 2021. DOI:10.3390/polym13213834. doi: 10.3390/polym13213834
[2]	ZOU Yi, REDDY Narendra, YANG Yiqi. Reusing polyester/cotton blend fabrics for composites[J]. Composites Part B: Engineering, 2011, 42(4): 763-770. doi: 10.1016/j.compositesb.2011.01.022
[3]	郑敏博, 张纯芳, 刘定会. 差异化多组分纤维混纺股线的生产[J]. 棉纺织技术, 2015, 43(11): 60-64.
	ZHENG Minbo, ZHANG Chunfang, LIU Dinghui. Production of differentiated multi-component fiber blended yarn[J]. Cotton Textile Technology, 2015, 43(11): 60-64.
[4]	SHI Qiuwei, SUN Jianqi, HOU Chengyi, et al. Advanced functional fiber and smart textile[J]. Advanced Fiber Materials, 2019, 1(1): 3-31. doi: 10.1007/s42765-019-0002-z
[5]	VÁZQUEZ Katherine, VANEGAS Paul, CRUZAT Christian, et al. Antibacterial and antifungal properties of electrospun recycled PET polymeric fibers functionalized with zinc oxide nanoparticles[J]. Polymers, 2021. DOI:10.3390/polym13213763. doi: 10.3390/polym13213763
[6]	WANG Wencai, CHENG Wenjian, TIAN Ming, et al. Preparation of PET/Ag hybrid fibers via a biomimetic surface functionalization method[J]. Electrochimica Acta, 2012, 79: 37-45. doi: 10.1016/j.electacta.2012.06.063
[7]	ZHAO Yi, CHEN Ranan, NI Ruiyan, er al. Fabrication and characterization of a novel facial mask substrates based on thermoplastic polyester elastomer fibers[J]. Journal of The Textile Institute, 2020, 111(8): 1231-1237. doi: 10.1080/00405000.2019.1702612
[8]	COSIMBESCU Lelia, MERKEL Daniel R, DARSELL Jens, et al. Simple but tricky: investigations of terephthalic acid purity obtained from mixed PET waste[J]. Industrial & Engineering Chemistry Research, 2021, 60(35): 12792-12797. doi: 10.1021/acs.iecr.1c02604
[9]	ASAKUMA Yusuke, YAMAMURA Yusuke, NAKAGAWA Kyuya, et al. Mechanism of depolymerization reaction of polyethylene terephthalate: experimental and theoretical studies[J]. Journal of Polymers and the Environment, 2011, 19(1): 209-216. doi: 10.1007/s10924-010-0263-3
[10]	WEI Ren, HAUGWITZ Gerlis V, PFAFF Llara, et al. Mechanism-based design of efficient PET hydro-lases[J]. ACS Catalysis, 2022, 12(6): 3382-3396. doi: 10.1021/acscatal.1c05856 pmid: 35368328
[11]	KIM Donghyun, HAN Dongoh, SHIM Kyuin, et al. One-pot chemo-bioprocess of PET depolymerization and recycling enabled by a biocompatible catalyst, betaine[J]. ACS Catalysis, 2021, 11(7): 3996-4008. doi: 10.1021/acscatal.0c04014
[12]	孙颖颖. 一步法废旧涤/棉纺织品组分分离技术及其纤维素应用研究[D]. 天津: 天津工业大学, 2021:16-22.
	SUN Yingying. Study on one-step separation technology of waste polyester/cotton fabric and its cellulose application[D]. Tianjin: Tiangong University, 2021:16-22.
[13]	吴慧萍. 废旧涤/棉织物低损伤开纤技术与应用研究[D]. 无锡: 江南大学, 2021:4-5.
	WU Huiping. Research on technology and application of low damage open fiber of waste polyester/cotton fabric[D]. Wuxi: Jiangnan University, 2021:4-5.
[14]	朱聪旭, 徐辉, 杨圆明, 等. SrAl₂O₄:Eu²⁺, Dy³⁺长余辉荧光材料的原位还原制备及其性能研究[J]. 硅酸盐通报, 2017, 36(11): 3648-3652.
	ZHU Congxu, XU Hui, YANG Yuanming, et al. In-situ reduction preparation and properties of SrAl₂O₄:Eu²⁺, Dy³⁺ long afterglow fluorescent materials[J]. Silicate Bulletin, 2017, 36(11): 3648-3652.
[15]	GUAN Zhipeng, DUAN Yangyinyi, LI Xiangping, et al. Up-conversion luminescence properties and temperature sensing behavior of Nd³⁺/Yb³⁺/Tm³⁺ triply doped LaNbO₄ phosphors under 808 nm and 980 nm excita-tions[J]. Radiation Physics and Chemistry, 2022. DOI:10.1016/j.radphyschem.2021.109786. doi: 10.1016/j.radphyschem.2021.109786
[16]	SHI Chen, SHEN Xiuyu, ZHU Yanan, et al. Facile synthesis of a color-tunable microcrystal phosphor for anti-counterfe it applications[J]. ACS Omega, 2020, 5(50): 32420-32425. doi: 10.1021/acsomega.0c04516 pmid: 33376879
[17]	俞沁岑. 夜光涤纶纤维中发光材料的回收及性能研究[D]. 无锡: 江南大学, 2021:22-28.
	YU Qincen. Study on recovery and properties of luminescent materials in luminous polyester fiber[D]. Wuxi: Jiangnan University, 2021:22-28.
[18]	史慕杨. 稀土铝酸锶的表面憎水改性及在夜光纤维上的应用[D]. 无锡: 江南大学, 2021:2-3.
	SHI Muyang. Surface hydrophobic modification of rare earth strontium aluminate and its application in luminous fiber[D]. Wuxi: Jiangnan University, 2021:2-3.
[19]	JIN Sebin, JEONG Jeamin, SON Seongyu, et al. Synthesis of two-dimensional holey MnO₂/graphene oxide nanosheets with high catalytic performance for the glycolysis of poly (ethylene terephthalate)[J]. Materials Today Communications, 2021. DOI:10.1016/j.mtcomm. 2020.101857. doi: 10.1016/j.mtcomm. 2020.101857
[20]	IKLADIOUS N E. Recycling of poly (ethylene terephthalate): identification of glycolysis products[J]. Journal of Elastomers and Plastics, 2000, 32(2): 140-151. doi: 10.1177/009524430003200203
[21]	AL-SABAGH A M, YEHIA F Z, EISSA A M F, et al. Cu- and Zn-acetate-containing ionic liquids as catalysts for the glycolysis of poly (ethylene terephthalate)[J]. Polymer Degradation and Stability, 2014, 110: 364-377. doi: 10.1016/j.polymdegradstab.2014.10.005
[22]	KONG Y, HAY J N. The enthalpy of fusion and degree of crystallinity of polymers as measured by DSC[J]. European Polymer Journal, 2003, 39(8): 1721-1727. doi: 10.1016/S0014-3057(03)00054-5
[23]	CHEN Chengho, CHEN Chuhyean, LO Yuwen, et al. Studies of glycolysis of poly(ethylene terephthalate) recycled from postconsumer soft-drink bottles: I: influences of glycolysis conditions[J]. Journal of Applied Polymer Science, 2001, 80(7): 943-948. doi: 10.1002/(ISSN)1097-4628
[24]	闫彦红. 夜光纤维用发光材料与纤维光色性能研究[D]. 无锡: 江南大学, 2014:22-23.
	YAN Yanhong. Research on luminescent Materials and optical and color properties of luminescent fiber[D]. Wuxi: Jiangnan University, 2014:22-23.
[25]	沈修宇, 朱亚楠, 葛明桥. SrAl₂O₄:Eu²⁺, Dy³⁺/TPE发光材料的制备及其光学性能[J]. 材料科学与工程学报, 2021, 39(1): 106-110,123.
	SHEN Xiuyu, ZHU Yanan, GE Mingqiao. Preparation and optical properties of SrAl₂O₄:Eu²⁺, Dy³⁺/TPE luminescent materials[J]. Journal of Materials Science and Engineering, 2021, 39(1): 106-110,123.
[26]	JIN Yang, LONG Xiaoyun, ZHU Yanan, et al. Optical performance study of Sr₂ZnSi₂O₇:Eu²⁺, Dy³⁺, SrAl₂O₄:Eu²⁺, Dy³⁺ and Y₂O₂S:Eu³⁺, Mg²⁺, Ti⁴⁺ ternary luminous fiber[J]. Journal of Rare Earths, 2016, 34(12): 1206-1212. doi: 10.1016/S1002-0721(16)60155-2
[27]	史慕杨, 晋阳, 葛明桥. 包覆CaF₂对稀土铝酸锶长余辉发光材料耐水性能的影响[J]. 化工新型材料, 2022, 50(1): 131-136.
	SHI Muyang, JIN Yang, GE Mingqiao. Effect of CaF₂ coating on water resistance of rare earth strontium aluminate long afterglow luminescent materials[J]. New Chemical Materials, 2022, 50(1): 131-136.
[28]	ZHANG Haoran, XUE Zhiping, LEI Bingfu, et al. A top-down method to fabricate SrAl₂O₄:Eu²⁺,Dy³⁺ nanosheets from commercial blocky phosphors[J]. Optical Materials, 2014, 36(11): 1802-1807. doi: 10.1016/j.optmat.2014.02.010
[29]	郭雪峰, 刘志香, 葛明桥. 稀土铝酸锶夜光机织物发光亮度的研究[J]. 上海纺织科技, 2013, 41(4):37-38,59.
	GUO Xuefeng, LIU Zhixiang, GE Mingqiao. Study on luminescence of rare earth strontium aluminate noctilucent woven fabric[J]. Shanghai Textile Science & Technology, 2013, 41(4):37-38,59.
[30]	KHOONKARI Mohammad, HAGHIGHI Amirhossein, SEFIDBAKHT Yahya, et al. Chemical recycling of PET wastes with different catalysts[J]. International Journal of Polymer Science, 2015. DOI:10.1155/2015/124524. doi: 10.1155/2015/124524
[31]	SHOJAEI Behrouz, ABTAHI Mojtaba, NAJAFI Moham. Chemical recycling of PET: a stepping-stone toward sustainability[J]. Polymers for Advanced Technologies, 2020, 31(12): 2912-2938. doi: 10.1002/pat.v31.12
[32]	KOSLOSKI-OH Sophiac, WOOD Zacharya, MANJARRE Z Yvonne, et al. Catalytic methods for chemical recycling or upcycling of commercial poly-mers[J]. Materials Horizons, 2021, 8(4): 1084-1129. doi: 10.1039/D0MH01286F
[33]	GUO Zengwei, LINDQVIST Karin, DELAMOTTE Hanna. An efficient recycling process of glycolysis of PET in the presence of a sustainable nanocatalyst[J]. Journal of Applied Polymer Science, 2018. DOI:10.1002/app.46285. doi: 10.1002/app.46285
